STG77S-E1G000-1-0AHS-11S-A-00A0-00-0000 Honeywell | In-line Gauge Pressure Transmitters
하니웰 인라인 게이지 압력 트랜스미터 신품 수입 문의
Manufacturer : Honeywell
Product No. : STG77S-E1G000-1-0AHS-11S-A-00A0-00-0000
Product type : In-line Gauge Pressure Transmitters
STG77S - Gauge In-Line
E - Process Head & Diaphragm Materials
Process Head/Reference Head Material : 316 Stainless Steel
Barrier Diaphragm Material : 306L ss
1 - Fill fluid : Silicone Oil 200
G - Process connection : 1/2" NPT (female)
0 - Bolt/Nuts Materials : none
0 - Vent/Drain Type/Location : none
0 - Gasket Material : None
1 - Head/Connect Orientation : Standard High Side Left, Ref Side Right2 / Std Head Orientation
0 - Approvals : No Approvals Required
A - Electronic Housing Material & Connection Type
Material : Polyester Powder Coated Aluminum
Connection : 1/2 NPT
H - Output/Protocol : Analog output 4-20mA dc,Digital protocol HART Protocol
Lighting protection : None
S - Customer Interface Selections
Ext Zero,Span & Config Buttons : None
Indicator : Standard(w/Internal Zero,Span&Config buttons)
Languages : EN
1 - Application software : Standard Diagnostic
1 - Output Limit, Failsafe & Write Protect Settings
Write Protect : Disabled
Fail mode : High> 21.0mAdc
High & Low Output Limits : Honeywell Std (3.8 - 20.8 mAdc)
S - General configuration : Factory Standard
A - Accuracy and Calibration
Accuracy : Standard
Calibrated range : Factory Standard
Calibration Qty : Single Calibration
0 - Mounting bracket : None
0 - Customer tag : None
A0 - Unassembled Conduit Plugs & Adapters : No Conduit Plugs or Adapters Required
00 - Certifications & Warranty : No Additional options
000 - Factory identification
Shipping weight : 5 Kg
