[수입판매] 3500/92 Communication Gateway Bently Nevada Asset Condition Monitoring 136188-02

3500/92 Communication Gateway Bently Nevada Asset Condition Monitoring 136188-02

통신 게이트웨이 벤틀리 네바다 어셋 컨디션 모니터링 수입판매

​

3500/92 통신 게이트웨이 모듈은 이더넷 TCP/IP 및 직렬(RS232/RS422/RS485) 통신 기능을 모두 사용하여 프로세스 제어 및 기타 자동화 시스템과 통합하기 위해 모든 랙 모니터링 값 및 상태에 대한 광범위한 통신 기능을 제공합니다. 또한 3500 랙 구성 소프트웨어 및 데이터 수집 소프트웨어와의 이더넷 통신을 허용합니다. 지원되는 프로토콜은 다음과 같습니다. ModiconModbus 프로토콜(직렬 통신을 통해) Modbus/TCP 프로토콜(TCP/IP 이더넷 통신에 사용되는 직렬 Modbus의 변형) 독점 Bently Nevada 프로토콜(3500 랙 구성 및 데이터 수집 소프트웨어 패키지와의 통신용) 이더넷 연결 3500/92는 10BASE-T 스타 구성 이더넷 네트워크용 RJ45 연결입니다. 3500/92는 기본 값 Modbus 레지스터를 제외하고 원래 3500/90의 통신 인터페이스, 통신 프로토콜 및 기타 기능을 지원합니다. 3500/92에는 이제 기본 값 Modbus 레지스터로 원래 처리되었던 동일한 기능을 제공할 수 있는 구성 가능한 Modbus 레지스터 유틸리티가 있습니다.

​

Part Number : [3500/92-AXX-BXX-CXX]

* A: I/O Module Type

0 1 ModbusRS232/RS422 I/O Module

0 2 ModbusRS485 I/O Module

0 3 Ethernet/RS232 ModbusI/O Module

0 4 Ethernet/RS485 ModbusI/O Module

* B: Memory Type

0 1 Low Memory

* C: Agency Approval Option

0 0 None

0 1 CSA/NRTL/C

0 2 CSA/ATEX



* Spares

138629-01 3500/92 Manual

04425545 Grounding Wrist Strap (single use)

137495-01 Firmware IC (Odd bank)

137494-01 Firmware IC (Even bank)

136180-01 3500/92 Communication Gateway Module.

125736-01 ModbusRS232/RS422 I/O Module.

133323-01 ModbusRS485 I/O Module.

136188-01 Ethernet/RS232 ModbusI/O Module

​
