B&R 6PPT30.101G-20B Power Panel T30, 10.1", landscape format. CPU and memory: 600 MHz 512 MB onboard flash drive
Power Panel T30, 10.1", landscape format. CPU and memory: 600 MHz (ARM Cortex-A8), 512 MB onboard flash drive. Display and touch screen: 10.1", 1024 x 600 (WSVGA) resolution, analog resistive touch screen, landscape format, anthracite gray pinstripe. Interfaces: 2x Ethernet 10/100 Mbit/s (integrated switch), 2x USB 2.0. Client software: Integrated service page, VNC client, embedded web browser.
General information
|
Cooling
|
Passive
|
|
LEDs
|
Ethernet
|
|
B&R ID code
|
0xE596
|
|
Power button
|
No
|
|
Reset button
|
No
|
|
Buzzer
|
Yes
|
|
Certifications
|
|
|
CE
|
Yes
|
|
EAC
|
Yes
|
|
UL
|
cULus E115267
Industrial control equipment
|
|
ATEX
|
Zone 2, II 3G Ex nA IIA T5 Gc
Zone 22, II 3D Ex tc IIIC T70°C Dc
Front IP65, back IP20
Ta (see user's manual)
TÜV 16 ATEX 7815X
|
|
DNV GL
|
Temperature: B(0 - 55°C)
Humidity: B(up to 100%)
Vibration: A(0.7 g)
EMC: B(bridge and open deck)
|
|
KR
|
Yes
|
Controller
|
Operating system
|
PPT30 system
|
|
Real-time clock
|
No
|
|
Processor
|
|
|
Type
|
ARM Cortex A8
|
|
Clock frequency
|
1 GHz
|
|
L1 cache
|
64 kB
|
|
L2 cache
|
256 kB
|
|
Flash
|
512 MB
|
|
Mode/Node switches
|
No
|
|
DRAM
|
256 MB
|
Display
|
Type
|
Color TFT
|
|
Diagonal
|
10.1"
|
|
Colors
|
16.7 million (RGB, 8 bits per channel)
|
|
Resolution
|
WSVGA, 1024 x 600 pixels
|
|
Contrast
|
Typ. 500:1
|
|
Viewing angles
|
|
|
Horizontal
|
L direction / R direction = typ. 80°
|
|
Vertical
|
U direction / D direction = typ. 80°
|
|
Backlight
|
|
|
Type
|
LED
|
|
Brightness
|
Typ. 500 cd/m²
|
|
Half-brightness time
|
50,000 h
|
|
Touch screen
|
|
|
Type
|
AMT
|
|
Technology
|
Analog resistive
|
|
Controller
|
B&R, 12-bit
|
|
Transmittance
|
80% ±3%
|
|
Screen rotation
|
Yes
|
Interfaces
|
Interface
|
|
|
Connection
|
ETH1 (IF1) and ETH2 (IF2)
|
|
Type
|
Ethernet
|
|
Variant
|
Shielded RJ45 (integrated 2-port switch)
|
|
Line length
|
Max. 100 m between 2 stations (segment length)
|
|
Max. transfer rate
|
10/100 Mbit/s
|
|
Transfer
|
|
|
Physical layer
|
10BASE-T / 100BASE-TX
|
|
Half-duplex
|
Yes
|
|
Full-duplex
|
Yes
|
|
Autonegotiation
|
Yes
|
|
Auto-MDI/MDIX
|
Yes
|
|
Interface IF3
|
|
|
Type
|
USB 2.0
|
|
Variant
|
Type A
|
|
Current-carrying capacity
|
0.5 A
|
|
Interface IF4
|
|
|
Type
|
USB 2.0
|
|
Variant
|
Type A
|
|
Current-carrying capacity
|
0.2 A
|
Electrical properties
|
Nominal voltage
|
24 VDC
|
|
Max. current at nominal voltage
|
429 mA
|
|
Max. power consumption
|
10.3 W
|
|
Fuse
|
4 A slow-blow, internal
|
|
Voltage range
|
8 to 32 VDC
|
|
Reverse polarity protection
|
Yes
|
|
Electrical isolation
|
Ethernet (ETH1/IF1 and ETH2/IF2) to other interfaces, power supply and ground
|
Operating conditions
|
Permissible mounting orientations
|
|
|
Standard mounting orientation
|
Vertical
|
|
Tilt
|
±25°
|
|
Rotation
|
In 90° increments (portrait/landscape)
|
|
Installation elevation above sea level
|
|
|
0 to 2000 m
|
No limitations
|
|
>2000 m
|
Reduction of ambient temperature by 0.5°C per 100 m
|
|
Degree of protection per EN 60529
|
Front: IP65, Back: IP20
|
Ambient conditions
|
Temperature
|
|
|
Operation
|
-20 to 60°C
|
|
Storage
|
-20 to 70°C
|
|
Transport
|
-20 to 70°C
|
|
Relative humidity
|
See temperature/humidity diagram.
|
