QBiX-Pro-BYTA1900H-A1

Industrial system with Intel® Celeron® J1900 Processor

​

GIGAIPC 산업용 임베디드 QBiX-Pro-BYTA1900H-A1

기가아이피씨

헬스케어, 키오스크, 임베디드, IoT 시스템, 산업자동화

드라이버 & 매뉴얼 다운로드

---

Key Features

System Size: 178W x 125D x 52.7H(mm)

Intel® Celeron® Processor J1900

Dual Channel DDR3L, 1 x SO-DIMM

HDMI, D-sub for Dual display

2 x GbE LAN ports

​

Application

Embedded & Industrial Applications

IoT System

Factory Automation

KIOSK / POS

Healthcare

---

Specification

QBiX Pro Series of GIGAIPC embedded system is implemented with GIGAIPC QBi Pro (3.5" SubCompact Board). Its fan-less design reduces the risk of fan failure and maintainance efforts. The aluminium heatsink and ruggedized chassis enhanced the ability to work in harsh environment. The Compact size can easily be designed in any applications in limited space, such as factory automation, industrial controller / Surveillance systems and IoT Gateway. Furthermore, it can be a computing solution dedicated to thin client, POS, KIOSK for commercial market.

QBiX-Pro-BYTA1900H-A1 is powered by Intel® Celeron® 1900 processor, to provide "low power but high performance" for energy-saving requests. It is designed with full range 9-36V DC power inputs for operating temperature of 0°C~50°C and rich I/O interfaces and expansion M.2 slots to fit in various applications. The system supports 2.5" HDD/SSD (SATA 3Gb/s) with vibration resistance of 5 Grms/5~500Hz and shock endurance to 50G/11ms, to meet industrial standard.

Dimension	178W x 125D x 52.7H(mm)
CPU	Intel® Celeron® Processor J1900 22nm, 4 cores, 4 threads, up to 2.42 GHz TDP 10W 2MB L2 cache
Chipset	SoC
Memory	1 x DDR3L SO-DIMM sockets, Max. Capacity 8 GB Support Single Channel DDR3L 1333MHz memory modules
Ethernet	2 x GbE LAN ports (Intel® i211AT)
Graphic support	Integrated Graphics Processor - Intel® HD Graphics 500: 1 x HDMI 1.4 port, supporting a maximum resolution of 3840x2160 @30Hz 1 x VGA port, supporting a maximum resolution of 2560x1600 @60Hz (with compatible displays) (2 independent display outputs)
Audio	Realtek® Audio Codec
Storage	1 x 2.5” HDD/SSD (SATA 3Gb/s)
Expansion Slots	1 x 2280 M.2 M-Key (SATA 3Gb/s) 1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G/4G module
Front I/O	2 x RJ45 LAN ports 1 x USB 3.0 1 x USB 2.0 1 x HDMI 1 x VGA 1 x Power switch 1 x Power & HDD LED 1 x Headphone jack
Rear I/O	2 x USB 2.0 1 x COM port (RS422/485/232 and RI/5V/12V) 3 x COM ports (RS-232) 1 x 3 pin Terminal Block
Side I/O	2 x External Antenna (Optional)
Power	+9~36VDC (Full Range)
Operation temperature	Operating temperature: 0°C to 50°C Operating humidity: 0-90% (non-condensing) Non-operating temperature: -20°C to 70°C Non-operating humidity: 0%-95% (non-condensing) Use wide temperature range memory and storage
Vibration During Operation	Operation: IEC 60068-2-64, 5 Grms, random, 5 ~ 500 Hz, 1 hr / Per Axis, With SSD/M.2 2242 Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 hr / Per Axis
Shock During Operation	Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With SSD
Packaging Content	Box Packing Capacity: 5pcs Carton size: 505x333x231(mm) Content: SCREW I HEAD FOR 25HDD M3x8L x 4 (P/N: 25KSG-130081-K1R) THERMAL PAD x 2 (P/N: 25ST3-200052-T5R) CABLE SATA x 1 (P/N: 25CF4-170020-S9R) TERMINAL BLOCKS MALE PLUG x 1 (P/N: 25IO0-5ESDV0-D2R)
Mounting	Wall mount (Optional)
Order Information	6BQP1900AMR-SI (Box packing)
Optional kit	TPM 2.0 module P/N: 9CTM000NR-00 TPM Cable P/N: 25CRZ-100600-S9R

​
